Mercury's subscriber incoming optical cable is an optical cable that connects to the in-house entrance. It is manufactured to have tensile strength and stable flexural characteristics in consideration of foaming strength during foaming, It has excellent mechanical and environmental characteristics in consideration of external pressure, shock, and climate change.
Excellent optical properties
Appropriate tensile strength
Lightweight than loose tube type, small diameter for covering
Excellent flexibility and flexibility
It's lightweight, so it's easy to pack indoors
Single-mode, multi-mode complex is available
A home subscriber network
FTTx tracks
For communication in apartments and on-site
| Category | 1C | 2C | 3C | 4C | |
|---|---|---|---|---|---|
| External diameter (mm) | 3.0 | 3.5 | 3.8 | 5.0 | |
| Weight (kg/km) | 8 | 11 | 14 | 25 | |
| allowable tensile load (kgf) | 50~100 | ||||
Minimum radius of curvature (mm) | mong the revelation | 20 times the outer diameter of the cable | |||
| after the revelation | 10 times the outer diameter of the cable | ||||
| Operating temperature range (℃) | -20 ~ +70 | ||||
| Sortation | SMF | MMF(62.5/125)-OM1 | MMF(50/125)-OM2 | MMF(50/125)-OM3 | MMF(50/125)-OM4 | |
|---|---|---|---|---|---|---|
| Loss factor (dB/km) | @1310nm | ≤0.40 | - | - | - | - |
| @1550nm | ≤0.30 | - | - | - | - | |
| @850nm | - | ≤3.5 | ≤3.0 | ≤3.0 | ≤3.0 | |
| @1300nm | - | ≤1.5 | ≤1.0 | ≤1.0 | ≤1.0 | |
* Follow IEC 60794-1 and EIA455 standards for cable performance
* Actual supplied cables may differ from the data in the table above
